Contents
1 x YD8230A-4UK-BL Console
1 x Outdoor Temperature & Humidity Sensor
UK Power Adapter (for EU orders, the EU version will be
supplied).
User Manual
Indoor Temperature
Operating temperature range 0°C to 50°C (32°F to 122°F)
Accuracy ± 1 degrees Celsius 0°C to 50°C (32°F to 122°F)
Indoor Humidity
Operating humidity range 1% RH to 99%RH
Accuracy +/- 5% RH (@25°C, 30%RH to 80%RH)
Accuracy +/- 8% RH (@25°C, 20%RH to 29%RH and 80%RH to
95%RH)
Accuracy +/-12% RH (@25°C, 1%RH to 19%RH and 96%RH to 99%RH)
Outdoor Temperature
Operating temperature range -30°C to 60°C (-22°F to 140°F)
Accuracy ± 1 Degrees Celsius from 0°C to 50°C (32°F to
122°F)
Accuracy ± 2 Degrees Celsius from -30°C to 0°C (-22°F to
32°F) and 50°C to 60°C
(122°F to 140°F)
Outdoor Humidity
Operating humidity range 1% RH to 99%RH
Accuracy +/- 5% RH (@25°C, 20%RH to 90%RH)
Accuracy +/- 8% RH (@25°C, 20%RH to 30%RH and 80%RH to
95%RH)
Accuracy +/-12% RH (@25°C, 1%RH to 19%RH and 96%RH to 99%RH)
Display Console: 152 x 112 x 41mmPower
Display Console: mains power, with optional battery backup
(3 x AAA batteries (not included)).
Remote Temperature Sensor: 2 x AAA batteries (not included)
Sensors
Sensor maximum transmission range: 30 metres
Sensor water-resistant to IP44 rating (protected against
rain and splashes)
RF frequency: 433.92 MHz
